TMC2208 is a single-axis，ultra-quiet stepping motor driver chip, power tube built-in drive current 1.4A peak current 2A, voltage range 4.75V-36V, 256 subdivision.StealthChop2 - faster motor acceleration/deceleration than stealthChop.Automatic stealthChop and spreadCycle switchover depending on the velocity
UART configuration interface (9600...500k Baud)，flexible microPlyer interpolation unit provides up to 256 subdivisions, allowing perfect sinusoidal control even in systems with limited pulse frequencies; faster motor acceleration/deceleration than stealthChop, these are also designed because stealthChop2 ultra-quiet technology is widely applied to 3D printing.
This TMC2208 Stempstick can replace the original TMC2100 A4988 DRV8825 LV8729.Plug and play, no wiring required.
TOP
I have and A20 with 2560 V4 mb, can I use another vendor TMC2208 without modification to the driver or 1.18 firmware?
Generally, we do not recommend using other brands of drivers. They may not work, and may cause strange bugs to damage your printer.
Thank you for your response, please let me know if the 2560 V4 mb is 8 bit or 32 bit and do these TMC2208 run as standalone in Marlin or UART mode? I want to upgrade Marlin 2.x, so setting driver up is important, your video does not show adjusting voltage, so it leave me with questions., thanks!
32 bit. in drive current 1.4A peak current 2A, voltage range 4.75V-36V, 256 subdivision. UART configuration interface (9600...500k Baud)
Why not TMC2209 in UART mode? A10/A20/M/T has been modified to use TMC2009 by the comunity. Plz level up, we love modz ;)
Hello, thanks for your advice, we will upgrade the new products and please wait for it.
Do I need the 4 pc for an A20?
It is best to change all of them, to make all of the X/Y/Z Axis motor and extruder quiet. Changing just anyone of them is ok and only the matched one will be quiet.
Buon giorno vorrei sapaere se posso mettere i TMC2208 sulla stampante A10 con scheda madre GT2560 Rev.B e cosa devo fare.
SÌ, puoi usarlo come modulo 4988, è pin to pin
Buon giorno a tutti. Vorrei mettere i TMC2208 sulla stampante A10 con scheda madre GT2560 V4.0.C'é qualcosa di particolare da fare? tipo fare correzioni sul firmware.Grazie a tutti. Cordialità. Gregorio
hello, do not need change firmware , but When install the driver , the driver direction need to be opposite from before A4988 direction; and also need change the line sequence of the motor cable at the end of the main board. https://www.youtube.com/watch?v=fmwMq9t-Nxc&t=40s
Grazie. Cordialità. Gregorio
Bonjour, je souhaite changer les driver a4988 par des TMC2208 pour l'imprimante A20 carte mère V4.0 merci de m'informer sur des informations technique si c'est possible ?quel est le bon firmware
hello, if you assemble TMC 2208 drivers , do not need change firmware , but When install the driver , the driver direction need to be opposite from before A4988 direction; and also need change the line sequence of the motor cable at the end of the main board.here is a video link for your reference , https://www.youtube.com/watch?v=fmwMq9t-Nxc&t=40s
