This V4.1B bord can only be a replacement for V4.1B board, can not replace V4.0 board or other board .
pls check which board does your printer has before order . the board type will be written on the board itself .
need order a same board as your printer originally has. otherwise will not be compatible .
A4988 stepper drivers are soldered on the board.
Here are its main features:
1. Using ATMEGA2560 as its core chip, with its flash memory at 256KB and operating frequency at 16MHz.
2. Compatible with 12V/24V input voltage. Featuring dual power supply, one for powering up the heatbed (15A), the other for other electronic parts (10A).
3. The interface for the heatbed comes with a high-power MOS tube, which is of ultra-low conductive internal resistance. High performance and stable.
4. With 2 interfaces for normally open fans and 1 interface for LED light.
5. Driven by 6 A4988 stepper motors for 3 extruders.
6. With extension interfaces for LCD display and SD card. Support 2004 or 12864 LCD display.
7. Support 3D touch auto-leveling function and filament detector.
8. Using Marlin firmware, stable and easy to operate.
9. Highly integrated and easy to assemble.
Specifications:
Net weight: 72g
Gross weight: 113g
TOP
Bonjour_br_J ai un souci j ai installer la nouvelle carte mais mon écran reste bleu pas d affichage_br_D ou pourrai venir le problème_br_Et si cela vient de l afficheur ou puis je trouver la pièce_br_Merci d avance_br_Cordialement
. Hi Fabrice, We have received your problems feedback. To solve your problems better, Please attach some pictures or videos of the product to illustrate the issues ,you can contact our technical support mailbox:support@geeetech.com or create a ticket on our official website, the ticket link is here:https://www.geeetech.com/index.php?main_page=ticket . Our tech support will give you professional printing advice and methods. If you need any help,you can also contact me at this email: myorder@geeetech.com. Have a nice day.
Hola , donde puede descargar el firmware de esa placa GT2560 V4.1B
Veuillez sélectionner le fichier dont vous avez besoin sur ce site Web. https://www.geeetech.com/download.html
hi, the price is the same for the board with 2208 drivers?
yes, you can order this one . but write a comment for your order , need it soldered with 2208 drivers instead
If I order this for my A20T, can Geeetech install TMC2209? Thank you
hello, we have this board soldered with TMC 2208 drivers , you can order this link board . but write a comment for your order , need A20T V4.1B board soldered with 2208 drivers instead
Heute kam das Board, vielen Dank. Leider läuft der Moto Y nicht. Alle anderen Motoren laufen. Wenn ich den Motor Y in den XMotorport stecke läuft der Y Motor ohne Probleme. Der X Motor läuft auf dem YMoto Port auch nicht. Also ist definitiv der Y Moto Port auf der Platine defekt. Auffällig ist das auf der Platine offensichtlich der YMoto repariert bzw. nachgelötet wurde, aber wohl nicht korrekt. Somit ist das Board defekt und kann so nicht verwendet werden. Nachdem ich mein altes Originalboard eingebaut habe laufen alle Motoren, allerdings wieder viel zu laut. Ich benötige ein funktionierendes Board für den A20T. Bitte teilen Sie mir mit wie der Austaus vorgenommen wird. Mfg. Bernd Rogge
Hello Bernd, if you need tech-support, please creat a ticket in you a account, "Home __ Account __ Ticket __ Ticket Detail " our tech support team will help you out your trouble. Thanks
