This power adapter is mainly used for Computer project and 3D printers.
Specification:
AC input voltage range:85-264VAC 47-63Hz
Input current: 110V /1.5A, 230V/0.75A
Output: 24V/ 0-15A
AC inrush current: Cold-start current 20A/115A 40A/230V
Leakage current: <1MA/240VAC
Dc adjustable range: +/_10% rated output voltage
Overload protection: 105%-135% hiccup mode, auto-recovery
Over-voltage protection: 115%-135% cut off the output, auto-recovery
Setup, rise, hold up time: 200ms, 50ms, 20ms.
Load regulation: +/_ 1%
Working temperature: -10℃~+60℃, 20%~90RH
Weight/size: 0.58kg, 199x 97x 42mm
Does this power supply work on the A20M? It seems quite different from the one that comes originally with the printer. Also it seems it doesn't have a fan to cool it down?
sorry for misunderstanding, i will upgrade the new picture. This psu do can use on a20m but the pictures is old one, sorry
