Hybrid stepper motor 42SHD0034-20B for 3D printer

  • Hybrid stepper motor 42SHD0034-20B for 3D printer
  • Hybrid stepper motor 42SHD0034-20B for 3D printer

Hybrid stepper motor 42SHD0034-20B for 3D printer

SKU: 700-001-0941 11 Reviews
$17.00
New Customers
Ship from: CN
CN
In Stock: Ship in 24 hours
Shipping: $10.35
QTY:
- +
Secure Payment
Multiple payment options
Payment options:
Customer Service Guarantee
DOA Guarantee
7 Days DOA Guarantee:
If your item arrives damaged, please contact us within 7 days and provide clear and valid proof. Geeetech will make compensation based on the damage situation.
View More
Missing/Wrong Items Guarantee
7 Days Missing/Wrong Items Guarantee:
If you receive a parcel with missing/incorrect/secondary packing items, please contact the merchant within 7days of delivery and provide relevant proof. Geeetech will make compensation based on the damage situation.
View More
Quality Guarantee
Quality Guarantee:
Some of Geeetech items enjoy [Quality Guarantee]. If the item you purchased has quality issues or problems caused by non-users, and enjoys "Quality Guarantee", Geeetech will provide comprehensive after-sale service.
View More
Recommendation
  • $45.90
  • $17.00
  • $23.00
  • $17.00
  • $17.00
  • $17.00
  • $17.00
  • $20.00
  • $36.90
  • $17.00
  • $2.90
  • $30.00
  • $28.00
  • $17.00
  • $19.90
  • $45.90
  • $17.00
  • $17.00
  • $17.00
Frequently Bought Together
Hybrid stepper motor 42SHD0034-20B for 3D printer
$17.00
  • Liquid Adhesive For 3D Printer heatbed Sticker PEI Plate Glass Plate , Help Release 3D Models from the Hotbed More Easily and Reduce Warping
  • PETG Transparent 3D Printer Filament 1.75mm 1kg/roll
  • Thunder LCD Screen to Control board link cable
  • Hotbed for Geeetech M1 3D Printer
  • Mizar S 3d printer motherboard control board
  • 35 copper hot bed aluminum substrate 235 (3mm thick)
  • PLA Grey 3D Printer Filament 1.75mm 1kg/roll
  • {5KG} ABS-Like Resin Black
  • {8KG}PLA Black 3D Printer Filament 1.75mm 1kg/roll
  • {5KG} ABS-Like Resin Grey
  • {12KG} PLA Grey 3D Printer Filament 1.75mm 1kg/roll
  • Filament Spool Holder
  • ALKAID Resin 3D Printer + 4 Bottles of Standard Resin Grey
  • {6KG} TPU Black 3D Printer Filament 1.75mm 1kg/roll
  • {8KG} TPU Transparent Blue 3D Printer Filament 1.75mm 1kg/rol8
  • PLA Wood 3D Printer Filament 1.75mm 1kg/roll
  • ABS+ Blue 3D Printer Filament 1.75mm 1kg/roll
  • 1 Meter Transparent Teflon Tube+2 pcs PC04-M6, 2 pcs PC4-M8,2pcs PC4-01 Pneumatic Straight Push Fittings,pls write a comment for your order, let us know you need the pust fittings for which model printer
  • {10KG} TPU Transparent Green 3D Printer Filament 1.75mm 1kg/roll
  • PLA Luminous White 3D Printer Filament 1.75mm 1kg/roll
Total Price
Selected 1 items
Price: $ 17.00
Add to cart
You May Also Like
  • Heatbed Aluminum Plate for A20/A20M/A20T
    $33.90
  • Pro B and Pro W Printer MK8 Extruder Holder
    $2.97
  • 3D Printer Brass M6 nozzle for MK8 extruder/0.3mm
    $2.20
  • GEX01 Dual-drive Gear Extruder
    $11.90
  • Ventilation Enclosure for Geeetech A10 A10M A20 A20M A30 PRO
    $7.99
  • A10Pro A10M A10T Magnetic Flexible Removable Printing Platform
    $12.99
  • Arduino LEONARDO
    $16.90
  • V4.1B Board Version A10T A20T A30T Extruder Extension Board Small Circuit Board
    $6.99
  • Stainless Steel Funnel, Resin Filter Cup for SLA/DLP/LCD Resin 3D Printer UV Resin, Strainer Filter for 3D Printing Liquid
    $12.89
  • A20 GT2560 V4.1B Control Board, before order pls check which board does your printer has
    $38.40
  • ABL Auto Leveling Kit for Mizar S Printer
    $26.80
  • A10/ A10 Pro/ A20/ A30 Pro 24V Printing Head, Single Extruder Hotend, 24V 40W, 110mm long heating rod, for V3.0/ V3.1/ V4.0 board version
    $17.90
  • Borosilicate glass platform 210*210*3mm for A10/A10M/A10T
    $6.90
  • 2pcs* 4020/DC 24V Cooling Radial Turbo Blower Fan with 120mm cable
    $3.99
  • Mizar S FDM 3d printer color touch screen
    $36.80
  • MK8 Dual Extruder
    $19.90
  • Mizar S/M Magnetic Flexible Removable Printing Platform, Rubber magnetic plate + stainless steel Mylar, 260*260mm
    $28.99
  • Arduino ADK Rev3
    $36.50
  • $13.00
  • Arduino Touch Button module
    $3.00
Top Selling
  • 1Stepper motor wire
    $2.90
  • 2Nema17 Stepper motor 42SHD3418-24B15
    $17.00
  • 3Arduino Touch Button module
    $17.00
  • 4I3 PRO B Printer S-180-12 12V 15A DC power supply
    $20.00
  • 5Stepper motor 42SHD0227-24B
    $17.00
  • Specification
  • Comments (11)

This is the stepper motor we use on the X/Y/Z axis for Geeetech Prusa I3 and Delta series 3D printers.



General specification

Step angle: 1.8°

Number of phase2

Insulation resistance100MΩmin. (500V DC)

Insulation classClass B

Rotor inertia38g cm2

Mass0.2kg

Wiring length: 700mm

Connector: XH (2.54mm-4pin)

Net weight: 232g

Shipping weight: 310g



Electrical specification

Rated voltage5V

Rated voltage: 1.0A

Resistance per phase: 5.0Ω±10%

Inductance per phase: 6.2mH±20%

Holding torque: 300mN.m

Detent torque: 12mN.m

login or register to add your words.

  • fabio bernardi   |   08/20/2020

      |   reply

    this is good for I3 B pro? thanks

    • Jocelin Jia   |   08/21/2020

        |   reply

      hello, you need extruder motor for PRO B printer , right ? the model is D42HS3418-24B22, it is not listed on our store , you can order this motor , but leave a comment for your order , need 700-001-1239 instead, i will change order for you when i process orders. send you the PRO B extruder motor


  • Clive KERR-PETERSON   |   08/26/2018

      |   reply

    My Geetech Aluminium Prusia i3 came with a faulty bearing which I have replaced. It now seems the Z axis L/H motor is faulty. Please could you advise my which is the correct one to replace it with, and should I replace both? Many Thanks

    • Jocelin Jia   |   08/27/2018

        |   reply

      can u tell me order number and send mails to jocelin.jia@geeetech.cn, thanks

    • Clive KERR-PETERSON   |   08/29/2018

        |   reply

      315127105604393

    • Jocelin Jia   |   08/30/2018

        |   reply

      there is no order info in our systerm, do you buy eleswhere? if yes,please find the seller for help,thanks


  • Stefano Alderighi   |   01/31/2018

      |   reply

    Hello. I want to use this motor in Full Step mode. How many Volt I set on the a4988 driver?

    • Jocelin Jia   |   03/15/2018

        |   reply

      Hi Stefano,the volt is about 0.8 to 1.2V,you can adjust to full step.Thanks


  • Ghislain Dimiglio   |   12/18/2017

      |   reply

    Hello, I have an Geeetech Prusa I3 aluminium. I want change the Z Stepper Motors. On Your web site, you sold 4 different motors. Can you give me the reference of the motor that match to my printer. Best Regards

    • Zina Luo   |   12/20/2017

        |   reply

      Hi Ghislain ,are you would like buy a new one ? You can place order online and remark use on Aluminum 3D printer so that i can arrange the original one to you ,Pls note with thank.


  • Lubomir Kalman   |   01/18/2017

      |   reply

    Hello I want ask if there is possibility to replace this stepper in my PI3 proB with one with step angle 0.9°
