Technology | FDM |
Printing Thickness | 0.1-0.2mm |
Printing Materials | PLA,ABS, PETG |
Printing Volume | 255*255*260mm |
Auto-leveling | Complimentary 3D Touch Leveling Sensor |
Break-Resuming Capability | Yes |
Hotbed Heating Time(110℃) | 11min |
Nozzle Diameter (mm) | 0.4 |
The Nozzle Number | 1 |
Positional Accuracy | X axis: 0.011mm Y axis: 0.011mm Z axis: 0.0025mm |
Printing Accuracy | ±0.1mm |
Printing Speed | 20~150mm/S |
Display | 3.5-inch Color Touch Screen |
Slicer | Repetier-Host, EasyPrint Lite, Cura |
Printing File format | .Gcode |
Hotbed Max Temperature | 110℃ |
Nozzle Max Temperature | 250℃ |
Working temperature | 10-40℃ |
Power Input | 115/230V AC, 50/60Hz |
Power Supply | DC24V-15A Max, 350W |
Port | 1*TF, 1*USB |
Hotbed Size | 260*260mm |
Net Weight | 10.2kg |
Gross Weight | 13kg |
Machine Size | 400(W)*465(L)*484(H)mm |
Package Size | 522(L)*482(W)*285(H)mm |
Hi I just want to know if the Mizar s hotend will work on my Mizar DIY
Hi if you have any problems you can contact my mailbox:myorder@geeetech.com , In order to solve your problem more efficiently , Please attach some pictures of the product to illustrate the issues , thanks for your cooperation , hope you have a good day .
Excellent printer and thanks to all at Geeetech
Hi thanks for your support and recognize, have anice day.
I just got this printer and the transparent extruder stop working and the filament is stuck in there and will not come out. I need a new one and don't see them on this site where can i get a new one from?
Hello , Please rest assured , this is transprent extruder link : https://www.geeetech.com/transparent-extruder-with-bracket-p-1606.html , welcome order it any time , hope you have a good day .
Where can I find the Config files for this system and if the boot loader is 28 or 32 bit?_br_
hello , regarding of config files problems , you can contact our technical support mailbox :support@geeetech.com or create a ticket on our official website ,In order to solve your problem more efficiently , Please attach some pictures of the product to illustrate the issues , thanks for your cooperation , hope you have a good day
I’ve never cared for dual color prints. In my experience you can do it once and e try subsequent print will show cross-contamination. The remedy is to have a dynamic head, and I’ve used a printer with one to make dissolvable supports and it worked well but it was a much more expensive machine with expensive repairs. I have an old Replicator Dual I use but only ever use one extruder.
Hello , Thanks for your coment , if you have aany questions you can contact my mailbox : myorder@geeetech.com , hope you have a good day .
I recently bought a Creatbox Dx triple extruder printer. It has been pretty painless after a few minor hiccups. User support is excellent.
Hello , Thanks for your support and recognize,welcome back again , hope hope you have a good day .
My print bed was sent to me with a multiple mm warp in the middle, also can this printer be klipperised because I would like to do that not only for bed mesh visualizer but also just further tuning because I can't get this thing figured out
Dear customer , you can contact our technical support mailbox :support@geeetech.com or create a ticket on our official website , In order to solve yo ur problem more efficiently , Please attach some pictures of the product to illustrate the issues , thanks for your cooperation , hope you have a good day .
This is my Third 3D Printer for GEEETECH and only one work for a week the other two NEVER printed good or at all. Maybe there is a setting I am missing or what. All I know is it will start to print then it will slowly start to move to the side and print will move off the side and spill Filament all over the place and have to throw the print out. ALL OF THEM DID THIS. So I might have to wait on ENDER to come out with one or just give up on duel color 3D printers?
Dear customer , you can contact our technical support mailbox :support@geeetech.com or create a ticket on our official website , In order to solve your problem more efficiently , Please attach some pictures of the product to illustrate the issues , thanks for your cooperation , hope you have a good day .
Tengo problemas con la impresión desde la MicroSD, no funciona. Instalé la última versión del firmware facilitado y no funciona. ¿Podrían facilitarme uno con versión anterior? La impresora venía con uno más antiguo instalado, pero lo primero que hice fue actualizarla. Por USB sí funciona.
Dear customer , thanks for your consult , about the firmware version of the machineyou can contact our technical supports mailbox :support@geeetech.com or create a ticket on our official website , thanks for your cooperation , hope you have a good day .
Don't waste your money on this model, it has been a headache since I got it. Can't find the gradient module nozzles, and just now the auto filament load/unload went out. Actually will not buy anything else from Geeetech cause I have several emails asking for where I can find parts for it, no response.
Dear customer , I'm really sorry for the trouble caused to you. I will replace the gradient module nozzle for you. if you have any problems you can contact me mailbox: myorder@geeetech.com .hope you have a good day .
My separated colour module quit after only a few months and I need a new one. What do I do to make that happen?
Dear customer , You can contact the after-sales customer service platform, they will replace the damaged machine parts for you, thank you for your support, you can contact our technical supports mailbox : support@geeetech.com or create a ticket on our official website ,hope you have a good day .
Hello. I'm interested in purchasing a printer from your company and would like to know which models support Functionally Graded Material (FGM) printing. Thank you in advance for your assistance.
Dear customer , Thank you very much for your support and recognition. You can learn more about the performance and price of each printer on our official website and choose a printer that suits you,this is product link :https://www.geeetech.com/geeetech-mizar-m-dual-extruder-multi-color-3d-printer-dual-z-axis-tmc2208-silent-drivers-print-volume-255x255x260mm-double-hotend-group-moduels-p-1393.html,hope you have a goo day .
Is there any difference between the Mizer M dual extruder being sold by Amazon for $569 versus your Mizer M sold at $369?
Please rest assured, there is no difference, because our website has a special promotion recently, the price will be more favorable, if you have any problems you can contact me mailbox : myorder@geeetech.com ,weolcometo you for ordering this machine , hope you have a good day .
I am trying to find the difference in models between Mizer M sold by Amazon at $569 versus here at $399. Amazon: https://shorturl.at/OW015_br_
Dear customer, Please rest assured, there is no difference, because our website has a special promotion recently, the price will be more favorable, welcome to you for ordering this machine , hope you have a good day .
Keep up the excellent work—I'm eagerly looking forward to your next post!_br_https://www.odysseytreksnepal.com/langtang-circuit-trek/_br_https://www.odysseytreksnepal.com/tilman-pass-trek/_br_
Dear customer, thanks for your supporting ,hope you have a good day .
I want to get the Mizar M multi color printer but unsure of its capabilities with TPU and carbon fiber filaments, any suggestions?
hello, You can play TPUs instead of carbon fiber, but it is usually used to make pigment models and mixed color models. You can see the user manual, M's function is here. thanks
Hello, where I can buy nozzle for gradient printhead and heatblock with a metal tube for separated color printhead for my Mizar M?_br_Maybe you can recommend similar ones?
hallo, Divide color SKU700-001-1527, mixed color SKU700-001-1528, the official website is not available at present, and it will be available after buying,https://www.geeetech.com/mizar-s-printer-hotend-full-kit-group-p-1346.html,this is my mailbox myorder@geeetech.com thanks
Hello, I'm looking to order a new build plate and nozzles for Mizar M, except I don't see any accessories available for this model. How do I order these parts?
hello, Mizar S and MizarM use the same size printing platform, and the nozzle is the same as the Mizar series. https://www.geeetech.com/mizar-s-magnetic-flexible-removable-printing-platform-rubber-magnetic-plate-stainless-steel-mylar-260260mm-p-1353.html https://www.geeetech.com/5pcs-nozzle-for-mizar-sm-mizar-3d-printer-04mm-nozzle-screw-thread-m6-p-1352.html
I wish to use the dual colour-separate facility to print with one of the spools containing the water-soluble PLA to make supports easy to get rid of - will I be able to do this with this printer?
Dear customer, you can contact our technical supports mailbox : support@geeetech.com or create a ticket on our official website ,hope you have a good day .
hello, sorry,This product cannot be printed with water-soluble PLA,if you any problem contact me ,you can use the email to contact me :myorder@geeetech.com thanks
Do you mean PVA? Please explain why not? Any hotend should be able to print pva.
Hi I got my new mizar m.what fillament can I use like tpu abs petg,plyflex tpu?thank you
Hello, all kind of filament can be used, you just need to follow the filament instruction to set the slice like print temperature or retraction and so on. Pls keep in mind that don't use different material filament to print a dual extruder printing, that usually cause a clog in the hotend.
Hello, I would be interested to know what firmware supports this machine (Marlin...) do you provide the source code of the firmware?_br__br_are all the outputs of the motherboard used? I would be interested to know in view of future improvements?_br__br_what is the delivery time to France?_br__br_Cordially
mizar m is already a mature printer, and the firmware will not be upgraded in the future, and this printer is not open source. Delivery time is about a week.
I have Geeetech filament and I keep my place pretty dry, filament stored in vacuum bags that I got from you, been working with the seperate color module and figured it out, the hot end does not heat up like it should, I put the big cleaning rod in the hotend and when I pull it out, you can hold the tool in your hand without burning, the display does not show any temperature change, how can I order a new one. I run 200c - 210c,
https://www.geeetech.com/a10m-a20m-12-pin-connector-hotend-group-assembly-with-pulley-bracket-for-gt2560-v40-control-board-version-p-1301.html Please click the above link to purchase, and note your printer model.
Just wondering how much does a seperated color module and a gradient color module cost, I don't see these listed upon ordering, having problems with mine, it wants to keep clogging up, I keep cleaning it out and still clogs back up
May I ask if the filament you used has been properly preserved, and is there any possibility of it being damp? What temperature do you set when slicing? You can try to use geeetech's filament printing.
